18650 battery 3.7V 10Ah lithium ion battery pack for solar light
18650 lithium ion battery pack with 3.7V 10Ah is widely used for solar light, LED, Flash light, power bank etc
Read More
18650 lithium ion battery pack with 3.7V 10Ah is widely used for solar light, LED, Flash light, power bank etc
Read More
FT555255P 3.7V 1500mAh used lipo battery built with PCM and it has high cycle lfe and super quality.
Read More
14.8V 3500mAh Li-ion Battery Pack used 4pcs INR18650GA in serials built with PCM to prevent over charge, over discharge, short circuit. The cycles life is more than 500 cycles. Original Sanyo cells
Read More
OEM ODM 18650 14.8 v Li-ion 4S1P 2000mAh 2200mAh 2400mAh 2600mAh 14.8v vacuum cleaner lithium battery
Read More
ICR18650 4S1P 14.8V 2200mAh battery pack for detector S/N Details Parameters Remarks 1 Rated voltage 14.8V 2 Rated capacity 2200mAh discharge with 0.2C to 5.5V after fully charge within 1h, measuring the discharge time 3 Limited charge voltage 16.8V 4 Internal resistance ≤ mΩ 5 charge mode C.C/C.V. 6 Standard charge current 440mA 0.2C 7 Max Charge Current 2200mA 1C 8 Standard discharge current 440mA 0.2C 9 Max Discharge current Continuous: 2200mA 1C 10 Working temperature charging 0~45℃ discharging -10~60℃ 11 Storage temperature 1 Month -10~45℃ Charge to 40%~50% of capacity when storage 6 months -10~30℃ 12 Storage humidity 45%~75％ relative humidity 13 Weight Approx 200g 14 Cycle life 300 times capacity≥80%
Read More
Item NO.:
FT2410ENominal voltage:
24VCapacity:
10AhBattery cell:
18650/3.7V/2000mAhDimension:
75 X 100 X 200mmApplication:
Motorcyle, E-bike, E-scooterFT2410E 24V 10Ah E Bike battery li-ion battery pack
|
S/N
|
Details
|
Parameters
|
Remarks
|
|
|
1 |
Nominal voltage |
25.9V |
Mean Operation Voltage |
|
|
2 |
Rated capacity |
Typical |
10Ah |
Standard discharge（0.2C） after standard charge |
|
Minimum |
10Ah |
|||
|
3 |
Charge |
Charge voltage |
29.4±0.2V |
|
|
Charge Moe |
0.2C to 29.4V, then 29.2V to 0.02C (CC/CV) |
|||
|
Standard Charge current |
2A |
|||
|
Max charge current |
5A |
|||
|
Charge cut-off voltage |
21±0.2V |
|||
|
4 |
Discharge |
Standard discharge current |
2A |
|
|
Max continuous discharge current |
10A |
|||
|
Max. Pulse current |
20A (＜3S) |
|||
|
Discharge Cut-off voltage |
20V |
|||
|
5 |
Cycle life |
≥ 500 cycles |
0.2C 100% DOD |
|
|
6 |
Operation Temperature Range |
Charge：0~45℃ |
60±25%R.H. Bare Cell |
|
|
Discharge：-20~60℃ |
||||
|
7 |
Storage Temperature Range |
0~35℃ |
60±25%R.H. at the shipment state |
|
|
8 |
Weight |
Approx：kg |
|
|
|
9 |
Size |
Customized |
|
|
|
10 |
PVC Wrapped |
|
||
FT7230E 72V30Ah Motorcycle battery uses high quality, high reliability 18650 li-ion cells.
FT4810E 48V 10Ah E bike battery uses high capacity, high reliabiliability li-ion cells.
S/N Details Parameters Remarks 1 Nominal voltage 12.8V Mean Operation Voltage 2 Rated capacity Typical 40Ah Standard discharge（0.2C） after standard charge 3 Charge Charge voltage 14.6±0.2V Charge Mode 0.2C to 14.6V, then 14.6V to 0.02C (CC/CV) Standard Charge current 8.4A Max charge current 20A Charge cut-off voltage 14.6±0.2V 4 Discharge Standard discharge current 8.4A Max continuous discharge current 40A Max. Pulse current 60A (＜3S) Discharge Cut-off voltage 10V 5 Cycle life ≥ 2000 cycles 0.2C 100% DOD 6 Operation Temperature Range Charge：0~45℃ 60±25%R.H. Bare Cell Discharge：-20~60℃ 7 Storage Temperature Range 0~35℃ 60±25%R.H. at the shipment state 8 Weight Approx：5.7kg 9 Size 197 x 165 x 170 mm 10 Plastic Case ABS
Lipo battery 502530 with 330mAh 3.7V for smart watch
li-polymer batteries 535056 with 3.7V 1500mAh for water purifier, hand warmer, level meter, alcohol tester
Lithium polymer battery 502530 with 3.7v 400mah for headset, MP3, digital products
